Screen frame: 370mm x370mm-737mm x 737mm

Thickness: 25~40mm

Minimum size of PCB: 50mm*50mm

Maximum PCB size Size: 400mm*340mm

PCB Thickness: 0.4~6mm

PCB Warpage: 11mm  including  PCB  thickness

Transportation height: 900±40mm

Running direction: left and right; right left; left left; right right

Transportation speed: Max 1500mm/S  programmable

Scraper speed: 6~ 200mm/sec

Squeegee pressure: 0~15Kg/cm2

Squeegee type: stainless steel (standard)

Stencil separation speed: 0.1~20mm/sec, OK Programming

Cleaning System: Dry/Wet/Vacuum (Programmable)

Printing Accuracy: ±0.025mm

Repeat Positioning Accuracy: ±0.01mm
